Drawing
239/710 CAK/W33
Specifications
| Principal dimensions (d) | 710 |
| Principal dimensions (D) | 950 |
| Principal dimensions (B) | 180 |
| Basic load ratings dynamic (C) | 4770 |
| Basic load ratings static (C0) | 12000 |
| Fatigue load limit (Pu) | 765 |
| Speed ratings Lubrication grease | 240 |
| Speed ratings Lubrication oil | 320 |
| Mass | 365 |
| Dimensions (d) | 710 |
| Dimensions (d2) | 788 |
| Dimensions (D1) | 881 |
| Dimensions (b) | 22.3 |
| Dimensions (k) | 12 |
| Dimensions (r mim) | 6 |
| Abutment and filet dimensions (da min) | 732 |
| Abutment and filet dimensions (Da max) | 927 |
| Abutment and filet dimensions (ra max) | 5 |
| Calculation factors (e) | 0.17 |
| Calculation factors (Y1) | 4 |
| Calculation factors (Y2) | 5.9 |
| Calculation factors (Y0) | 4 |
