Product
Drawing
23940 CC/W33
Specifications
| Principal dimensions (d) | 200 |
| Principal dimensions (D) | 280 |
| Principal dimensions (B) | 60 |
| Basic load ratings dynamic (C) | 620 |
| Basic load ratings static (C0) | 1040 |
| Fatigue load limit (Pu) | 93 |
| Speed ratings Lubrication grease | 1600 |
| Speed ratings Lubrication oil | 2000 |
| Mass | 11.5 |
| Dimensions (d) | 200 |
| Dimensions (d2) | 222 |
| Dimensions (D1) | 258 |
| Dimensions (b) | 8.3 |
| Dimensions (k) | 4.5 |
| Dimensions (r mim) | 2.1 |
| Abutment and filet dimensions (da min) | 211 |
| Abutment and filet dimensions (Da max) | 269 |
| Abutment and filet dimensions (ra max) | 2 |
| Calculation factors (e) | 0.19 |
| Calculation factors (Y1) | 3.6 |
| Calculation factors (Y2) | 5.3 |
| Calculation factors (Y0) | 3.6 |
