Drawing
248/530 CAK30MA/W20
Specifications
| Principal dimensions (d) | 530 |
| Principal dimensions (D) | 650 |
| Principal dimensions (B) | 118 |
| Basic load ratings dynamic (C) | 1840 |
| Basic load ratings static (C0) | 5300 |
| Fatigue load limit (Pu) | 380 |
| Speed ratings Lubrication grease | 380 |
| Speed ratings Lubrication oil | 480 |
| Mass | 86 |
| Dimensions (d) | 530 |
| Dimensions (d2) | 573 |
| Dimensions (D1) | 612 |
| Dimensions (b) | – |
| Dimensions (k) | 7.5 |
| Dimensions (r mim) | 3 |
| Abutment and filet dimensions (da min) | 543 |
| Abutment and filet dimensions (Da max) | 637 |
| Abutment and filet dimensions (ra max) | 2.5 |
| Calculation factors (e) | 0.15 |
| Calculation factors (Y1) | 4.5 |
| Calculation factors (Y2) | 6.7 |
| Calculation factors (Y0) | 4.5 |
